PROFAX WP-500 - Daily Maintenance

®
®
4
WP-500 Parts List
TROUBLE SHOOTING
1. No power 1. Check power supply for 110VAC 50/60Hz.
Indicator Light Fails to light 2. Fuse blown 2. Check and replace fuse.
3. Faulty indicator light 3. Check and replace indicator light.
4. Faulty power switch 4. Check and replace power switch.
1. Tilt/Rotate switch in TILT position 1. Change to “Rotate”.
2. VR set at 0 position 2. Adjust it.
Table fails to turn 3. Foot switch 3. Check and replace Foot switch.
4. The Relay R3, R4 4. Check and replace R3, R4.
5. Circuit board 5. Check and replace.
Table will not tilt 1. Tilt/Rotate switch in Rotate position 1. Change it to “Tilt”.
2. The Relay R3, R4 2. Check and replace.
3. Circuit board 3. Check and replace.
PROBLEM POSSIBLE CAUSE SOLUTION
NO. PART NO. DESCRIPTION
1. PX9997 Table
2. PX7000 Table Shaft
3. PX7001 Tilt Base
4. PX9995 Table Motor
5. PX9959 Tilt Gear
6. PX7002 Tilt Gear Shaft
7. PX9957 Pinion Gear
8. PX9956 Tilt Gear Box
9. PX7003 Tilt Bearing
10. PX7005 Top
11. PX9994 Motor Tilt
NO. PART NO. DESCRIPTION
12. PX9960 Table Gear Box
13. PX7006 Table Ground
14. PX7007 Tilt Shaft
15. PX9996 Limit Switch
16. PX7010 Cover Plate Rear
17. PX9955 Control Box Complete
18. PX9991 Cover Plate Front
19. PX9958 Base
20. PXCFS404 Foot Switch
21. PX9984 PC Board Fuse 10A 5mm x 20mm (Not Shown)
22. PX9967 Fuse Main Power 10A (Not Shown)
1
13
16
18
17
10
8
9
15
11
12
3
2
4
6
5
7
20
19
14
®
®
Daily Maintenance
*NOTE: INSPECT & REPAIR BEFORE OPERATION.
• Inspect table ground for proper ground tension against table. (Positioners)
• Check oil level in gear cases & fill if necessary. (WP-500/WP-1000/WP-2000)
• Inspect foot pedal and/or pendant for proper operation.
• Test limit switches if applicable.
• Test operation of power switch and/or emergency stop button.
• Check for any broken wires, loose connections, worn parts or damages before operation.
• Apply grease to all gears and grease fittings. (Weekly)
