Ref. : 840000015 Manual
Eltra nv, Pachtgoedstraat 2, 9140 Temse, BELGIUM 1
A. Functions
1. The Programmable Digital Timer (hereinafter refer as “Timer”) can preset specific on/off time of your home
electrical appliances. It is ideal for energy saving and home security.
2. The countdown function can switch on/off your appliance on your pre-set time and random functions allows you to
switch on and off the appliance in irregular time, it is not only ideal for home automation, also prevent burglary
during your absence.
3. The LCD displays program setting status and real time.
4. With maximum 140 on/off programs per week .
B. Image and description
Shows time and program setting.
Return to real time display when in program setting
press together with SET Button to set real time and week
press together with ∨－Button to change to Summer Time
Press the button to start/stop countdown program when it is in AUTO status
Press the button to start/stop random program when it is in AUTO status
Change the setting mode to ON, ATUO or OFF. When press the button each time, the
horizontal line in the LCD moves to ONAUTOOFF which were silk printed on the
Timer
To set time and week and to confirm setting
Press the button to reduce the time, week or program group
Press the button to increase the time, week or program group
S function
(summer-/winter
hour)
Press CLOCK Button and ∨－ Button at the same time to change to Summer Time. Time
display adds one hour automatically and “S” are shown on the LCD.
Press once to reset all your preset programs
Connect your appliance to the socket and plug the timer to the wall AC socket to get
power
220-240V ~ 50Hz
Max resistive capacity: 3680W (16A)
Max inductive capacity: 920Va (4A)
Weekly programming
Adjustable in periods of 1 minute
Countdown function
Random function : creates a domestic situation by
turning your devices on/off at irregular times
Summer-/winter time
With manual ON/OFF switch
