Model RMC-FA300PF
11
RMC-FA300PF
ProFitter
TM
Operating Instructions and Parts Manual
Repair Parts List for Propane Construction Heater
1 Inner Shell Assembly 2315586 1
2 Screw 2001355 6
3 Frame Holder 2315587 1
4 Screw 2001355 3
5 Nut 2000112 2
6 Sleeve 2315511 2
7 Thermal Switch 2201153 1
8 Screw 2001059 2
9 Nut 2305686 1
10 Spark Plug Assembly 2315582 1
11 Bolt 2001447 3
12 Burner Top 2315603 1
13 Inner Ring 2315602 1
14 Burner 2315601 1
15 Nut 2000121 3
16 Burner Tube Assembly 2315600 1
17 Outer Shell 2315575 1
18 Handle Assembly 2101447 1
19 Screw 2000416 2
20 Nut 2000384 2
21 Motor Assembly 2315590 1
22 Fan Assembly 2315592 1
23 Motor Support 2315584 1
24 Motor Bracket 2315591 1
25 Fan Guard 2315500 1
26 Screw 2001355 3
27 Thermostat Assembly 2201186 1
28 Screw 2000375 2
29 Clip 2301973 1
30 Screw 2000375 1
31 Nut 2000231 1
32 Capacitor 2201586 1
33 Bushing Strain Relief 2101633 1
34 Power Cord Assembly 2201163 1
35 Switch 2201549 1
36 Solenoid Valve 2315449 1
37 Screw 2001206 2
38 Connector Inlet 2315595 1
39 Fitting 2315596 1
40 Solenoid Valve Bracket 2315594 1
41 Screw 2000416 2
42 Nut 2000384 2
43 Back Pressure Switch 2201594 1
44 Base Lower 2315589 1
45 Screw 2001355 6
46 PCB Assembly 2201181 1
47 Screw 2001445 2
48 Nut 2000231 2
49 Base 2315588 1
50 Plastic Tube 2101052 1
51 Aluminum Tube Bracket 2315700 2
52 Screw 2001355 4
53 Aluminum Tube 2315699 1
54 Tubing Assembly 2315599 1
55 Nozzle Base 2315598 1
56 Nozzle 2315597 1
57 Knob 2101207 1
Regulator & Hose Assembly KR-126-10-31
Ref. Part
No. Description No. Qty.
Ref. Part
No. Description No. Qty.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Use only original
replacement parts. This
Heater must use design-
specific parts. Do not substitute or use
generic parts. Improper replacement parts
could cause serious or fatal injuries.
58 1
10 ft (3m)
KR-126-15-31
Regulator & Hose Assembly
15 ft (4.6m)
E
N
G
L
I
S
H
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com
