ProFitter RMC-FA300PF - Wiring Diagram

Gas
Valve
Yellow
White
Blue
White
Motor
Black
White
Red
White
Yellow
Green
Black
White
Line
Neut
Valve
Ground
Line Cord
Ground
PCB Assembly
High Limit
Switch
on / off
Thermostat
Spark Plug
Black
Back
Pressure
Switch
Green
Black
Orange
White
8
ProFitter
TM
Operating Instructions and Parts Manual
RMC-FA300PF
If any original wiring as supplied with the heater must be
replaced, it must be replaced with type AWG105°C wire or its
equivalent except as indicated (∗Type SF2-200, ∗∗SGI-250°C)
Figure 8 – Wiring Diagram
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
E
N
G
L
I
S
H
ProFitter
TM
Propane Construction Heater
For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:30 am - 4:30 pm CST www.ghpgroupinc.com
