M12 Nylon Locknut (36)Ð1
M6 x 40mm Bolt (27)Ð4
M10 x 95mm Bolt (49)Ð4
M8 x 60mm Bolt (48)Ð1
M6 x 65mm Bolt (41)Ð1
M6 x 15mm Screw (29)Ð6
M8 Nylon Locknut (45)Ð1
M10 Nylon Locknut (35)Ð10
M6 Washer (44)Ð11
M8 Washer (46)Ð2
10mm Washer (34)Ð14
M10 x 70mm Bolt (31)Ð2
