Progressive Dynamics PD1610 User Manual

16
Specifications
*All ratings at 25 °C unless otherwise listed
SPECIFICATIONS
PHYSICAL SPECIFICATIONS TRANSFER SWITCH
PD1610 PD1618 PD1620 PD1610 PD1618 PD1620
Dimensions
L:11.2”(284mm)
W:6.7”(170mm)
H:4.0”(101mm)
L:15.0”(381mm)
W:7.9”(200mm)
H:4.0”(101mm)
L:15.0”(381mm)
W:7.9”(200mm)
H:4.0” (101mm)
Transfer Voltage 95 - 135 VAC
Transfer Time < 50 msec
Net Weight 7 lbs (3.2 kg)
11 lbs (5.0 kg) 11 lbs (5.0 kg)
Pass Through
Ampacity
20 AAC
30AAC
AC OUTPUT DC INPUT
PD1610 PD1618 PD1620 PD1610 PD1618 PD1620
Waveform Pure Sine Wave Nominal Voltage 12.0 VDC
Output
Voltage
120 VAC
Under-Voltage
Shutdown
10.5 VDC
Max Power
(Cont)
1000W
1800W 2000W
Under-Voltage
Restart
12.0 VDC
Max Power
(Peak)
2000W
3600W 4000W
Over-Voltage
Shutdown
15.5 VDC
Frequency 60 Hz
Over-Voltage
Restart
15.0 VDC
Peak
Efficiency
90%
Max Current @
max load
100 ADC 180 ADC 200 ADC

Progressive Dynamics PD1610 Specifications

General

Brand	Progressive Dynamics
Model	PD1610
Category	Inverter
Language	English
