Proheat M80 - 1.1 PHYSICAL

PROHEAT M-SERIES SERVICE MANUAL
1-2
4X M8X1.25
MOUNTING PEM NUTS
6X
Ø.41 (10)
Ø2.75 (70)
1.40 (36)
2.13 (54)
3.94
(100)
8.20 (208)
4.93
(125)
9.53 (242)
.75 (19)
8.61
(219)
5.37
(136)
7.63
(194)
9.00 (229)
1.97 (50)
9.55 (243)
2X
1.50 (38)
12.60 (320)
3.23
(82)
5.90
(150)
4.33
(110)
23.30 (592)
4.45
(113)
5.77
(147)
-4 JIC MALE FUEL INLET
(INTERNAL FUEL FILTER)
SERVICE SPACE
REQUIREMENT
(SEE NOTE 3)
BOTTOM VIEW
TOP VIEW
SIDE VIEW
FRONT VIEW
REAR VIEW
INLET
OUTLET
THE INLET AND OUTLET CAN
BE REVERSED WITH THE
ADDITION OF A SECONDARY
TEMPERATURE SENSOR
EXHAUST (SEE NOTE 4)
PCM
1. DIMENSIONS ARE IN INCHES (MILLIMETERS IN BRACKETS).
2. TYPICAL EXHAUST CUTOUT 3.25" CENTERED ON EXHAUST.
3. SERVICE SPACE REQUIRED TO REMOVE BURNER HEAD AND COMBUSTION TUBE FOR PERIODIC
INSPECTION AND CLEANING.
4. THE EXHAUST PIPE SHOULD HAVE A MINIMUM DIAMETER OF 2.75", A MAXIMUM LENGTH OF 5'
AND HAVE NO MORE THAN 180 DEGREES OF BENDS.
NOTES:
PHYSICAL1.1
