PROHEAT M-SERIES SERVICE MANUAL
2-3
BLOWER HOUSING
FUEL
SUPPLY
PUMP
FUEL REGULATOR
FUEL
NOZZLE
FUEL
SHUT-OFF
VALVE
AIR COMPRESSOR
IGNITION MODULE
PCM (PROHEAT CONTROL MODULE)
COMBUSTION TUBE
HEAT EXCHANGER
TEMPERATURE SENSOR 1
TEMPERATURE
SENSOR 2
(IF EQUIPPED)
COMBUSTION AIR BLOWER
MOTOR
BURNER HEAD FLANGE
AIR FILTER
IGNITION
ELECTRODES
