Page 22 X30 Owner’s Handbook
START (01) & FLAME OUT (02) Diagnostic Code
PROHEAT is designed to burn Diesel (ULSD #1, #2 and Arctic Blend), Kerosene (K-1), Jet (A, A-1 and JP8),
Bio fuels (up to B20* ). During cold weather, the correct grade of fuel or fuel blend MUST be used to
prevent gelling and to ensure fuel flow. Problems with the fuel system are indicated by the above codes.
Fuel level in tank and quality of fuel:
• Fuel line
routing for kinks and restrictions (wire ties too tight, etc.)
• Fuel line condition (cracks, abrasions, etc.)
• Fuel filter (see Installation and Service manual SL9211
at www.proheat.com)
Troubleshooting
Function Diagnostics
Six consecutive start (01) faults will put the
PROHEAT into Lockout Mode. It requires power
to the X30 PCM to be removed for 30 seconds
and reapplied to clear the code.
Notice
check
Notice
On a new installation, running out of fuel or after
servicing, the fuel lines may be empty and two (2)
ignition cycles may be required in order to purge
the air from the fuel system when starting.
Hose
Fuel Tank
Fuel Pick Up
Crimp Clamp x2
Hose Crimp Connection
Fuel In Line
* For biofuels higher than B20, contact PROHEAT www.proheat.com
