Project Timber Evolution My Den 8x6 - Page 22

Silicone sealant can be added around
the edges of the window frames
Silicone Sealant - optional
* Silicone sealant
is not provided with
the building.
Repeat previous stage
where silicone sealant
is applied.
Silicone Selant - optional
The window frames can also be sealed with
silicone sealant around the edges where the
window frames meet the timber framing.
Silicone Sealant - optional
Internal Cover Trims
Fit the top architrave over
the battens on the window
frame. Secure the
architrave using panel pins
See top window
architrave detail.
ID: 21080
Top Window Architrave Detail
Top window
architrave
Window
frames
Window
battens
Door Stop fixing
28mm x 28mm
x 250mm
Door Stop
50mm
Screws
Pilot drill holes
before fixing
ID: PT21074
