UPVC Single Door Glazing Unit fixing
Rubber
fitting
strip
Insert the rubber
packing strip to the
top to secure the
glazing unit. Add a
couple of rubber
fittings if necessary
to tightly fit the
glazing unit to the
window frame.
UPVC Single Door Glazing Unit fixing
Position the bottom UPVC
beading to the bottom
door frame. Use a hammer
and a wood cut-off to
gently knock the beading.
ID: 19655
UPVC Door Frame and UPVC Beading
UPVC
Beading
UPVC
Beading
Door
Glazing
UPVC Door
Frame
Front
Back
UPVC Single Door Glazing Unit fixing
Position the side
UPVC beading
to both sides of
door frame to
secure the
glazing unit.
ID: 19655
The uPVC door
frame can be sealed
with silicone sealant
where the edges
meet the timber
framing.
* Silicone sealant
is not provided with
the building.
Silicone Sealant - optional
UPVC Single Door Glazing Unit fixing
Position the top UPVC
beading to the upper
section of door frame.
Repeat previous stage
to fit the beading
ID: 19655
69
72
73 74
70 71
