PANEL FIXING
Check the panel dimensions.
“Check the
dimensions of
your wall panel parts"
HOBBYIST PENT
ASSEMBLY INSTRUCTIONS
STAGE 2
page on mobile"
"Pinch to zoom the
Pilot drill holes before fixing
50mm
Screws
Side
Back
1
2
Pilot drill holes
before fixing
Fix the back panel and side
gable together. Secure the
panels to the floor
Back
Side
Plain Panel
1
Floor
Assembly
Gable Panel
2
Wall Panel Position
5
