PANEL FIXING
Check the panel dimensions.
“Check the
dimensions of
your wall panel parts"
HOBBYIST PENT
ASSEMBLY INSTRUCTIONS
STAGE 2
page on mobile"
"Pinch to zoom the
Pilot drill holes before fixing
18mm
Wall Panel
Floor
Panel
Side View
1812mm
18mm 18mm
Side View
Front
Back
Wall Panels and Floor Panels Position
50mm
Screws
Side
Back
1
Pilot drill holes
before fixing
Position the back panel and
secure to the floor panels.
Wall Panel Stage
18mm
3
4
