7
1.5 Water Tank Probe
For PM435, a maximum of 4 probes can be monitored.
NOTE: Always check the probe required for the water tank before purchase. There are 2 probe styles:
Figure 6 PMWS200 Figure 7 PMWS400
PMWS200:
• Side installation
• Suitable for water tank
• Depth >200mm
PMWS400:
• Side installation
• Suitable for water tank
• Depth 300-400mm
1.4 Bedroom Switch Panel (not inc. PM435-BT)
With two bedroom switches, the PM400 offers extra customisation
Figure 5 An overview of Switch Panel
PM4SW2
No. NAME TYPE DESCRIPTION
1 Bedroom light DC load control Load control, support brightness adjustment
2 Night light Scene mode Load control, support brightness adjustment.
Refer to Chapter 2.11
Table 2 Function list of PM4SW2
Note: Dimming function may not be compatible with some capacitive touch lights..
