9
Part No. PH125
Inverter
Input Voltage Range 10.5V – 15.0 Vdc
Input Current ≤ 32A
Open Circuit Output Voltage 240±5% Vac
Full Load O/P Voltage 240±5% Vac
Output Frequency 50±0.5Hz
Continuous Output Power 300VA
Surge Output Power 600VA for 0.2s
Output Waveform Pure Sinewave
Protection
Overload with Auto-recovery 360 – 450VA
Input Overvoltage 15.5±0.5Vdc
LVD 10.5±0.2VDC
Reconnect Input Voltage after LVD 12±0.2VDC
Overtemperature Auto-recovery
Reverse Polarity By Fuse
Battery Fuel Gauge
Input Voltage Range 6.0 – 17.0 Vdc
Display Resolution
Current 0.1 A
Voltage 0.1V
Battery Capacity 0.1Ah
Type of Battery Supported Lead Acid
Power Outlets
2 x 10A Accessory Socket Resettable Fuse Protected
2 x 15A Merit Socket Resettable Fuse Protected
1 x 10A Engel Type Socket Resettable Fuse Protected
1 x 50A Heavy Duty Battery Connector Resettable Fuse Protected
1 x DC Terminal –
2 x 2A USB Ports Short-circuit protected
1 x 300VA AC Socket Overload and Short-circuit Protected
Physical Characteristics
Weight 5.5 kg
External Dimension 390mm (L) x 235mm (W) x 337mm(H)
Maximum Battery Dimension Allowed 230mm x 177mm x 338mm*
Operating Temperature 0 to 50
o
C
Compliance
EMC Certified to meet AS/NZS 61000.6.3
Safety Tested to meet AS/NZS 4763
SPECIFICATIONS
*See drawing over the page
