- 19 -
Motor unit assembly
1.
2.
3. Loosen the cable clamp screw (k) on the motor connector. Place the power cord (l) through the cable clamp
(m). Then fix the screw back. (fig. 8)
Note: The length of the power cord between the motor unit and the cable clamp cannot be too short. Make
sure there is enough space in between so that the fan head can operate smoothly for swing function.
fig.8
Make sure the top point of
the bolt is correctly aligned
with the groove in the hole.
To Next Page
