3. Cut away the not needed part of the Flex Strip, with a scissor, at the marked cutting line.
4. Please pay attention, that an already sticked Flex Strip should not be removed again. It is possible that
electronical parts or soldering points will break, which isn’t covered by guarantee or warrenty.
5. Rest pieces can be used at other project. Only connection cable must be soldered to the Flex Strip.
6. Connection diagram
Following diagrams show the connection of Flex Strips. Please refer to the manual of your controller/dimmer for
exact connection diagram.
Connection of monochromatic Flex Strips without dimmer
