OVEN OVERVIEW
1) Door lock
Microwave oven door must be properly closed in order for it to operate.
2) Viewing window
Allow user to see the cooking status.
3) Rotating ring
The glass turntable sits on its wheels; it supports the turntable and helps it to
balance when rotating.
4) Rotating axis
The glass turntable sits on the axis; the motor underneath it drives the turntable
to rotate.
5) Turntable
The food sits on the turntable, its rotation during operation helps to cook food
evenly.
CAUTION
- Place the rotating ring first.
- Fit the turntable onto the rotating axis and make sure that it is geared in properly.
1 2 3 4
5 6
7
