Page 17
Error message:Temperature sensor is not properly connected or damaged (display at the end of a
program).
Troubleshooting:
NTC exist open circuit .Replace it
Y
Check if NTC is connected properly
Cut off power and measure the resistance
of temperature sensor by multimeter, is
it between 5-14k ?
Y
N
Connect NTC well
N
Check the wries of NTC, are they connected
well.
Y
Disconnect the white wire and black wire
from PCB, and measure if the resistance
between white wire and black wire of PCB is
it infinite?
N
Replace PCB
Connect all wires well
N
Replace wire
Y
Error message:The heater may be broken
Troubleshooting:
Y
Cut off power, check the resistance of
two pins of heater element by multimeter,
is it between 32-35
?
Heater element
must be broken,
please replace it
N
The control wire may be broken,
otherwise PCB must be broken.
Please replace the broken one.
N
Check if overload of laundry
Y
Reduce the laundry
Front Load Washing Machine
Model:
PFL1266W-E/F
