8 15
Fault and warning code
Fault Code Event Audible Alarm
A64 Overload Rapid beeping every 1/2 second
A68 High Temperature Beep every second
A88 PV Voltage High Beep every second
A89 PV Current High Beep every second
A91 PV Charger NTC Disconnect Beep every second
E07 Output Voltage High Constant tone
E09 Output Short Constant tone
E14 Overload Fault Constant tone
E18 Fan Fail Constant tone
E13 Over Charge Constant tone
E25 Output Voltage Unbalance Constant tone
