ProLogic K3 - Page 3

R1. Lautsprecher
R2. LEDs (grün, gelb, rot, blau, lila, weiß)
R3. Carbonhülle
R4. Batterietyp: 3 x AAA (nicht im Lieferumfang)
R5. Bivvy Light (3 mögliche Optionen)
OFF Dauerhaft ausgeschaltet
ON/ OFF Manuelles Ein- und Ausschalten
AUTO/ Automatisch - wird durch mindestens 4 Piepgeräusche in 3 Sekunden ausgelöst.
R6. Anwinkelbare Antenne
R7. Batteriewarnung (2.4V)
In einem 10 minütigen Abstand ertönen 3 Pieptöne. Nach einer Stunde endet die Warnung.
R8. Knöpfe:
– lange gedrückt halten zum Ein- und Ausschalten, kurz drücken für die Bivvylight
Einstellungen
– lange gedrückt halten zum Einstellen der Tonhöhe (4 Optionen) - kurz drücken, um die
Lautstärke
einzustellen (5 Optionen inkl. Lautlos mit Vibration)
– lange gedrückt halten, um neue Bissanzeiger anzulernen - kurz drücken, um den letzten
Biss anzeigen zu lassen
R9. Recieverhalterung mit magnetischer Platte
Reciever-Hülle mit Gürtelclip (im Lieferumfang)
R1. Hautparleur multimédia
R2. Diodes de touche ( vert, jaune, rouge, bleu, pourpre, blanc)
R3. Corps en carbone
R4. Pile: 3 x AAA (non fournies)
R5. Lampe de bivvy, 3 options disponibles
OFF (tout le temps)
ON/OFF à déclenchement manuel
Auto – s’allume quand la centrale reçoit 4 bips continus en moins de 3 secondes
R6. Antenne inclinée pour une couverture maximale
R7. Indicateur de batterie faible ( 2.4V )
3 signaux sonores toutes les dix minutes, qui cessent au bout d’une heure
R8. Boutons
– pression longue et maintenue pour ON/OFF, pression courte pour sélectionner l’option
lampe de bivvy souhaitée
– pression longue et maintenue pour le réglage de tonalité ( 4 tonalités), pression courte
pour le volume ( 5 niveaux disponibles dont le mode silencieux avec vibreur)
 –pressionlonguepourenregistrerunmode,pressioncourtepourafcherladernière
touche
R9. Centrale munie d’un socle magnétique
Coffret de transport avec accroche-ceinture
DE
FR
K3 ALARM
1.Two places for isotope
2.Rubble plate for rod
3.Left button:
Short press:Volume:0(silence) to 3
Long press:Mute 30 seconds
4.Bite Light:
Run=Left+right flash,continue 15 seconds
5.Battery:CR2*1
6.Low power warning(2.4V)
10 minutes warning 3 times ;stop after 1 hrs
7.Range:150M~300M
8.Drop back=right flash,continue 15 seconds
9.Right button:
Short press:sensitivity 1-5
Long press:Power off/on
10.Green,yellow,red,blue,purple,white
11.Carbon shell
12.Small size (Φ32*79mm)
13.Rubber ring on the boby:
Extra increase Green/Yellow/Red/Blue/
Purple/White in a plastic bag
14.TPR case for bite alarm
K3R RECEIVER
1 2
1
4
5
8
9
11
2
3
6
10
7
12
14
13
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R1.Multinmedia speaker
R2.Bite lights:
Green,Yellow,Red,Blue,Purple,White
R3.Carbon shell
R4.Battery:3*AAA
R5.Bivvy light
A)Clour:White
B)Mode:Always on,Always off,
Automatic(trigger when continuous bites)
R6.Collapsible antenna
R7.Low power warning(4V)
10 minutes warning 3 times ;stop after 1 hrs
R8.Buttons
A)First button:Long press for power on/off;
Short press for Bivvy light on/off
B)Middle button:Long press for Tone(1-4);
Short press for Volume(0-4)
C)Bottom button:Short press for memory(last
bite light);Long press for register
R9.Sling with buckle
R10.Rubber base (magnet) with Metal plate.
It can fix on the bivvy,also available on Bivvy
table
Battery Type:CR2*1 PCS for Alarm
Battery Type :AAA*3 PCS for Receiver
