ProLogic K3 - Page 4

R1. Multimedia speaker
R2. LED’s ( groen, geel, rood, blauw, paars, wit )
R3. Carbon buitenmantel
R4. Batterijen: 3 X AAA ( niet inbegrepen )
R5. Bivvy verlichting , 3 opties beschikbaar
Volledig uit
AAN/UIT handmatig
Automatisch – gaat aan na 4 doorlopende piepjes binnen een periode van 3 seconden
R6. Gerichte antenne voor optimale ontvangst
R7. Lage batterij spanning ( 2.4V )
Gedurende 10 minuten worden 3 waarschuwingspiepjes gegeven. Dit tot max1 uur lang
R8. Knoppen
– lang indrukken en vasthouden voor AAN/UIT, kort drukken voor bivvy verlichting opties
– lang indrukken en vasthouden voor de toon( 4 verschillende tonen), kort indrukken voor
volume ( 5 niveaus inclusief stil/vibratie )
– lang indrukken voor registratie mode, kort indrukken voor geheugen (laatste aanbeet )
R9. Ontvangervoet met magnetische bivvy bevestiging
Ontvanger hoes met riemclip ( bijgeleverd )
R1. Wielofunkcyjnygłośnik
R2. Diodysygnalizacyjne(zielona,żółta,czerwona,niebiska,oletowa,biała)
R3. Obudowazwłóknawęglowego
R4. Baterie:3xAAA(niedołączone)
R5. Lampkanamiotowa,dostępne3trybypracy:
 Całkowiciewyłączona
Sterowanie manualne
Sterowanie automatyczne
R6. Antenawzmacniającasygnał
R7. Sygnałniskiegopoziomunaładowaniabaterii(2,4V)
 W10minutowychodstępach3sygnałydźwiękowe,zatrzymaniepojednejgodzinie
R8. Przyciski:
 –długienaciśnięcie:włączenie/wyłączenie,krótkienaciśnięcie:wybórtrybupracylampki
namiotowej
 –długienaciśnięcie:wybórtonu(dostępnesą4tony),krótkienaciśnięcie:ustawienie
  poziomugłośności(dostępnychjest5poziomówgłośności,wtymtrybycichyiwibracyjny)
 –długienaciśnięcie:włączenietryburejestratora,krótkienaciśnięcie:pamięćostatniego
brania
R9. Stacjadokującazmagnesemdozamontowaniacentralkiwnamiocie
Pokrowieccentralkizklipsemdopaska(dołączony)
NL
PL
K3 ALARM
1.Two places for isotope
2.Rubble plate for rod
3.Left button:
Short press:Volume:0(silence) to 3
Long press:Mute 30 seconds
4.Bite Light:
Run=Left+right flash,continue 15 seconds
5.Battery:CR2*1
6.Low power warning(2.4V)
10 minutes warning 3 times ;stop after 1 hrs
7.Range:150M~300M
8.Drop back=right flash,continue 15 seconds
9.Right button:
Short press:sensitivity 1-5
Long press:Power off/on
10.Green,yellow,red,blue,purple,white
11.Carbon shell
12.Small size (Φ32*79mm)
13.Rubber ring on the boby:
Extra increase Green/Yellow/Red/Blue/
Purple/White in a plastic bag
14.TPR case for bite alarm
K3R RECEIVER
1 2
1
4
5
8
9
11
2
3
6
10
7
12
14
13
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R1.Multinmedia speaker
R2.Bite lights:
Green,Yellow,Red,Blue,Purple,White
R3.Carbon shell
R4.Battery:3*AAA
R5.Bivvy light
A)Clour:White
B)Mode:Always on,Always off,
Automatic(trigger when continuous bites)
R6.Collapsible antenna
R7.Low power warning(4V)
10 minutes warning 3 times ;stop after 1 hrs
R8.Buttons
A)First button:Long press for power on/off;
Short press for Bivvy light on/off
B)Middle button:Long press for Tone(1-4);
Short press for Volume(0-4)
C)Bottom button:Short press for memory(last
bite light);Long press for register
R9.Sling with buckle
R10.Rubber base (magnet) with Metal plate.
It can fix on the bivvy,also available on Bivvy
table
Battery Type:CR2*1 PCS for Alarm
Battery Type :AAA*3 PCS for Receiver
K3 ALARM
1.Two places for isotope
2.Rubble plate for rod
3.Left button:
Short press:Volume:0(silence) to 3
Long press:Mute 30 seconds
4.Bite Light:
Run=Left+right flash,continue 15 seconds
5.Battery:CR2*1
6.Low power warning(2.4V)
10 minutes warning 3 times ;stop after 1 hrs
7.Range:150M~300M
8.Drop back=right flash,continue 15 seconds
9.Right button:
Short press:sensitivity 1-5
Long press:Power off/on
10.Green,yellow,red,blue,purple,white
11.Carbon shell
12.Small size (Φ32*79mm)
13.Rubber ring on the boby:
Extra increase Green/Yellow/Red/Blue/
Purple/White in a plastic bag
14.TPR case for bite alarm
K3R RECEIVER
1 2
1
4
5
8
9
11
2
3
6
10
7
12
14
13
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R1.Multinmedia speaker
R2.Bite lights:
Green,Yellow,Red,Blue,Purple,White
R3.Carbon shell
R4.Battery:3*AAA
R5.Bivvy light
A)Clour:White
B)Mode:Always on,Always off,
Automatic(trigger when continuous bites)
R6.Collapsible antenna
R7.Low power warning(4V)
10 minutes warning 3 times ;stop after 1 hrs
R8.Buttons
A)First button:Long press for power on/off;
Short press for Bivvy light on/off
B)Middle button:Long press for Tone(1-4);
Short press for Volume(0-4)
C)Bottom button:Short press for memory(last
bite light);Long press for register
R9.Sling with buckle
R10.Rubber base (magnet) with Metal plate.
It can fix on the bivvy,also available on Bivvy
table
Battery Type:CR2*1 PCS for Alarm
Battery Type :AAA*3 PCS for Receiver
