Prolon PL-VC2000 - Auxiliary Analog Input; Operation

REV 1.0 / PL-QCK-WSENSOR/VC2000-EN12
Digital Sensor (PL-T1000)
Auxiliary Analog Input
The T1000 has auxiliary analog input which can be used to connect
another thermistor. The T1000 can be congured to use this alternate
temperature reading for a variety of functions, including temperature
averaging or radiant oor slab temperature. The alternate thermistor
(10KΩ type 3) can be connected to the auxiliary input using the “AUX
IN“ and “COM“ pins. (See gure below)
Analog Input
Operation
The T1000 is controlled using the circular touch pad on the bottom half
of the thermostat. The touch pad uses capacitive sensing technology
to detect nger proximity. There are no moving parts to push or rotate.
The T1000 is controlled using simple scrolling, tapping or holding
motions, performed around the circle of the touch pad. The center of
the circle is unused.
Scroll clockwise or
counterclockwise
to adjust or navigate
Tap here to
ENTER
Tap here to
go BACK
