Prolon PL-VC2000 - Digital Sensor (PL-T500); Dimensions and Wiring

REV 1.0 / PL-QCK-WSENSOR/VC2000-EN8
Digital Sensor (PL-T500)
Dimensions and Wiring
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
Schedule override:
Hold 3 seconds
Change unit °F/°C:
Double-click
