COMMISSIONING
a)
Lubricate the spindle and column with PROMAC oil Part no. 100385.
b)
Check that the surface of the clamping table is free of dust, chips or oil residues.
212 / 212Z
c)
Check that the machining tool is sharp and properly clamped, and that the workpiece is securely
clamped.
d)
Make sure that the setting of the spindle speed is not too high and that the cutting speed is appropriate
for the task to be done.
e)
Make sure that everything is prepared before starting the work.
NOTE: before initial operation
a)
The V-belt is not tensioned to avoid distortion. Before use, please tension the belt as described page 17.
b)
Before operating the machine for the first time, let it run in for 1/2 hour without load at approx. 1200 rpm.
AFTER OPERATION
a)
Switch off the machine and disconnect it from the mains.
b)
Unclamp the tool.
c)
Clean the machine, oil bare parts, guides and spindles.
d)
Cover the machine with a cloth to protect it from dust and dirt.
ADJUSTMENT AND SETTING OF THE WORKTABLE
Always wear safety googles!
a)
To raise or lower the worktable, loosen the clamping lever so that the table can be raised and lowered
on the column via the rack.
When the desired height is reached, tighten the clamping lever again to avoid vibrations.
b)
The worktable can be rotated 360° after loosening the clamping screw. Once the desired angular
position has been set, tighten the clamping screw again.
ADJUSTMENT FOR DRILLING
a)
Set the drilling depth using the depth stop.
b)
The drilling feed is now carried out by turning the cross handle.
T-SLOTS ON WORKTABLE AND BASE
For safe working, the workpiece must always be firmly clamped on the cross table using a suitable
clamping tool. The T-slots in the worktable have a dimension of 12 mm. A large selection of suitable
clamping tools can be found in the PROMAC metalworking machines catalogue.
14
