SPEED SETTING
212 / 212Z
By shifting the V-belt, the desired speed can be set according to the table below.
1.
Switch off the machine and disconnect it from the mains.
2.
Open the V-belt cover.
3.
Loosen the set screw.
4.
Push the motor against the head housing to release the V-belt.
5.
Change the V-belt position on the pulleys.
6.
Tension the V-belt by means of the motor (approx. 1cm sag).
7.
Close the V-belt cover and start the machine.
17
