6.2-DC65200P00
NO. PART NO. DESCRIPTION Q'TY NOTES
DC64271000 Welded body (FB ; PK)
DC65218000 Welded body (TB;TK)
2 DC64272000 Main shaft 2
3 D80K203000 Bearing bracket 2
4 D80K204000 Bearing bracket 2
5 D80K205000 Washer 4
6 D80K206000 Bracket - Spring, Top 2
7 D80K207000 Bracket-Spring ,Bottom 2
8 DC65208000 Tension spring 4
9 D80K210000 Spring mounting bar 4
10 DC64211000 Spring adj. screw 4
11 2708012 Spring pin 4
12 DC53207000 Spring pull shaft 4
13 D80K212000 Sensor plate 3
14 D80K213000 Sensor plate 3
15 DC80216001 Solenoid valve mounting plate 2
16 2911805 Solenoid valve VT317-9D-02 AC24V 1
17 29100050 Air regulator SMC AR20-02H 1
18 DC80215000 Limit switch bracket 2
19 2853313 Limit switch TZ-7311 3
20 2861022 Fitting - electric conduit, MG Type MG-25A-18B 1
21 2861021 Fitting - electric conduit, MG Type MG-20A-14B 2
22 2909002 Fitting, P-12 1/4”x1/4” 1
23 29090312 Speed control valve - L type VSL-8x1/4" 2
24 29093431 Iron fitting 1/4 x 5/16 1
25 2700403 Hex head screw M6 x 50 6
26 2700441 Hex head screw M8 x 35 2
27 27004011 Hex head screw M6 x 20 6
28 2701152 Hex socket head screw M6 x 16 4
29 27011551 Hex socket head screw M6 x 35 8
30 2703311 Round head screw M4 x 30 2
31 27033161 Round head screw M4 x 60 2
32 2705306 Split lock washe M4 4
33 2705302 Split lock washe M6 16
34 2705154 Split lock washe M4 4
35 2705151 Split lock washe M6 12
1 1
27
