6.3.4-DC642PKP0G
NO. PART NO. DESCRIPTION QTY NOTE
1 DC80202000 Cover - vacuum suction 1
2 2705154 Flat washer M4 2
3 2705306 Split lock washer, M4 2
4 2703308 Round head screw M4 x 12 2
5 DC64251000 Cushion bar- bottom (PK) 4
6 3114463 Sealing silicon 4
7 D80K256000 Silicon bar end insert 8
8 DC64253000 Cushion bar (PK) 4
9 D80K224000 Inner plate 4
10 2701164 Socket set screw M4 x 10 8
11 DC64221000 Nut - bottom cushion bar support shaft 8
12 2740168 O-ring 8
13 DC80211000 Nut - bottom cushion bar support shaft 8
14 2704603 Socket set screw M6 x 10 8
15 27020347 Flat philip screw M4 x 16 20
16 3114471 Sealing silicon 4
17 DC64255000 Support shaft - bottom cushion bar 16
18 2703327 Round head screw M4 x 20 16
19 D80K413001 Gas nozzle (FB) 20
OPTION
20 D80K414000 Gas nozzle nut 20
OPTION
21 DC64273000 Flat plate 4
22 2909057
Pin-copper tube 1/8x5/16
8
A DC642PKG00 Cushion bar assembly (PKG) 4
36
