6.3.5-DC642TBP00
NO. PART NO. DESCRIPTION QTY NOTE
1 DC80202000 Cover - vacuum suction 1
2 2705154 Flat washer M4 2
3 2705306 Split lock washer, M4 2
4 2703308 Round head screw M4 x 12 2
5 DC64263001 Sealing bar- bottom(TB) 4
6 D88K286000 Isolated plate-heating 8
7 D88K289000 Isolated plate 8
8 VA04277000 Spring 8
9 D80K224000 Inner plate 4
10 2701164 Socket set screw M4 x 10 8
11 DC80210000 Nut - bottom sealing bar support shaft 8
12 2740168 O-ring 8
13 DC80211000 Nut - bottom sealing bar support shaft 8
14 D88K287000 Fitting-heating 8
15 D88K288000 Joint plate - fitting 8
16 D88K284000 Sealing wire plate 8
17 2703307 Round head screw M4 x 10 16
18 3114463 Sealing silicon 4
19 3200955 Teflon tape 4
20 2824011115 Sealing wire 4
21 3200955 Teflon tape 4
22 DC64267000 Teflon tape clamp 8
23 2703325 Round head screw M4 x 8 40
24 2867290 Cap 24
25 DC64273000 Flat plate 4
26 2740171 O-ring 8
27 DC80212000 Cap 8
A DC642TB000 Sealing bar assembly- bottom (TB) 4
38
