PROMARKS DC-650 - Page 57

54
ITEM PART NO. DESCRIPTION SPECIFICATION Q’TY NOTE
KM1 2810755 Contactor DILMP20 (AC24V) 1
KM2 2810745 Contactor CU-18-B5 (AC24V) 1
2811513 RHN-10K (8.5~12.5A)
2811514 RHN-10K(12.5~18A)
OL
2811515
Overload Relay
RHN-10K(5.5~8.5A)
1 Option
2830132 Relay RU4S-C-A24 1
2831106 Socket, Relay SY4S-05D 1
R1
2850636 Hook PYC-A1 2
F1 2890048 Fuse 20mm 1A 1
F2 2890046 Fuse 20mm 5A 1
2890068 20mm 15A(380~480V)
F3~F4
2890069
Fuse (FB)
20mm 25A(200~240V)
2 Option
2890068 20mm 15A(380~480V)
F3~F5
2890069
Fuse (TB)
20mm 25A(200~240V)
3 Option
F5 2890070 Fuse (FB-Fan) 30mm 0.5A 1
F6 2890070 Fuse (TB-Fan) 30mm 0.5A 1
FAZ1~2 2
FAZ1~3
2801734 Breaker FAZ-C32/1
3 TB
2833328 Time Relay ANLY AMY-2 6S AC24V 1
2833329 Socket Relay PYF08A-E MY2 1
TMR1
2850635 Hook FM-4 2
2896065
0F-200-220V/0-24V.0F-
24V CE
28960652 380V-415/0-24 OF-24
T1
28960654
Transformer
TBSW-1I-120VA
0F-400V/0-24V.0F-24V
1 Option
T2~T3(FB)
T2~T4(TB)
2896048
Transformer
500VA
0F-200-220/0-30 2
