Promation Engineering P2 DC Series User Manual

Page 17 of 17 P2/3 12 24 VDC Proportional Series
Drawn By
Finish
Promation Engineering Inc.
16138 Flight Path Drive
Brooksville, Fl 34604
Phone: 352-544-8436
Fax: 352-544-8439
This Document is the property of ProMation Engineering,
Inc. Distribution of this document without the written
consent of the owner is Strictly forbidden.
Failure to comply will incur a liability for Damages.
Checked By
2/9/2021
P2-3 S and L Imperial Dimensional Data
Rev.
A
NO SCALE
She
et Number: 1
Material
ProMation Engineering, Inc.
DJG
PMR
2/9/2021
P2_3 S and L DimData.idw
Created:
Last Checked:
Part No.
Dwg. Name
Dimensional Data for P2-3 S and L Imperial Mount Actuators
Engineering Change Notice
Change Date
Description
Name
02.09.2121
New using P2-3 S .... DimData.idw as model layout
DJG
REV
A
B
C
D
E
F
Dimensional Tolerances (Unless Otherwise Noted):
X
± 2.5mm [X.X ± .1]
X.X ± .3mm [X.XX ± .01"]
X.XX ± .13mm [X.XXX ± .005"]
ALL TOLERANCE FEATURES IN mm
1
1
2
2
A A
B B
F
D
d
93 mm
3.7 in
318 mm
12.5 in
Add 257mm
[10.1"] to allow
for cover
removal
208 mm
8.2 in
123 mm
4.8 in
85 mm
3.3 in
B 1
D
F
(2) 1/2" NPT
EMT Entry
231 mm
9.1 in
55 mm
2.2 in
B 2
P2-3 L
P2-3 S
L
Dimensions
Model
Unit
D F d L BHC1 B1
B1
Depth
BHC2 B2
B2
Depth
P2-3 S in 0.75 0.5 1.26 4.1 3.25 ⅜-16 UNC 0.56
mm
19.05
12.7
32 105 82.6
14.2
P2-3 L in 0.875 0.625
2
6.1 3.25 ⅜-16 UNC 0.56 5 ½-13 UNC 0.63
mm
22.23 15.88 50.8
154
82.6 14.2 127 16
BHC 1
BHC 2
Single
Mount
Only
P2/3 Series Dimensional Data
Imperial Mount
Mechanical Data
|--- Add 33 mm (1.30 in) for -TS ---|
FM_P28 24 PN4-DC Ver E 080223
