Promation Engineering P2 DC Series User Manual

Contents
2 . . . . . . . . . . . . . . . . . . . Product Specifications
3 . . . . . . . . . . . . . . . . . . . Shipping and Handling
3 . . . . . . . . . . . . . . . . . . . Product Mounting and Setup
3 . . . . . . . . . . . . . . . . . . . Installation Notes
4 . . . . . . . . . . . . . . . . . . . Wiring Diagram
4 . . . . . . . . . . . . . . . . . . . Torque Switches
5 . . . . . . . . . . . . . . . . . . . Layout of Controller
6 . . . . . . . . . . . . . . . . . . . Check End of Travel Settings
6 . . . . . . . . . . . . . . . . . . . Status Indicators
7 . . . . . . . . . . . . . . . . . . . Adjusting the actuator CW position
8 . . . . . . . . . . . . . . . . . . . Adjusting the actuator CCW position
9 . . . . . . . . . . . . . . . . . . . Adjusting the actuator Auxiliary Switches
10 . . . . . . . . . . . . . . . . . . Mechanical Data
11 . . . . . . . . . . . . . . . . . . Mechanical Data
12-14 . . . . . . . . . . . . . . . Commissioning
15 . . . . . . . . . . . . . . . . . . AutoCalibration Procedure
IOM Template Master.indd
Page 1 of 17 P2/3 Series HV-TS AdVanced Proportional Control
Page 1 of 17 P2/3 12 24 VDC Proportional Series
Product
Family
Torque Output Voltage Options
in lbs Nm 12DC 24DC 24AC 120AC 230AC
P2
800 90
    
P3
1,335 150
    
P4
3,500 400
    
P5
4,400 500
    
P6
5,750 650
    
P7
8,900 1,000
   
P8
13,250 1,500
   
P9
17,500 2,000
 
P10
22,000 2,500
 
P11
26,500 3,000
 
P12
31,000 3,500
 
P13
40,000 4,500
 
Field Manual
P(S)2,3 24(12)-PN4-DC
High Resolution
Proportional Control w Loop Feedback
ISO5211 F07/F10 8P22
Imperial Mount S 3.25in BHC, 0.75x0.5in DD
Imperial Mount L 3.25/5in BHC, 0.875x0.625in DD
Actuator Sizes and Voltage Opons
ISO 5211
Mount
Imperial
Mount
Actuators In
This IOM
FM_P28 24 PN4-DC Ver E 080223
