Setting menu
Item Function Description
Language Setting Set the required language Opens a sub menu screen.
Choose the required language from the list.
Menu Time Set how long the menus are displayed 5s, 10s, 15s, 20s, 30s, or Always
HDMI Settings Adjust settings related to the HDMI Opens a sub menu screen. (See separate table
below)
Source Scan Set if the panel scans for connected devices Manual/Automatic/Off
Movie Mode Off/On
Backlight Setting Adjust backlight settings Opens a sub menu screen. (See separate table
below)
Boot Setting Set how the panel should boot up Opens a sub menu screen. (See separate table
below)
Temperature Setting Set the unit of temperature to be displayed on the
menu
Centigrade/Fahrenheit
No signal shutdown Set if the panel shuts down if no source signal is
found
Off/On
HDMI output format Controls HDMI output quality. Default is 1920 x 1080
Network Info View network information. Displays the MAC address and network IP
Restore To Default
Settings
Restore the factory default settings Opens a dialog window OK/Cancel
Standby Time Set how long the panel is idle for before it enters
standby
2min, 5min, 10min, 20min, or 30 min
Shutdown Time Set how long the panel is idle for before it shuts down 30min, 60min, 120min, 180min, 240min, or Never
Version Shows the current panel firmware version
TC FW Version Shows the touch controller version number
TC Serial No. Shows the touch bezel serial number
HDMISettings menu
Item Function Description
Color Range Set the displayed color range Auto, 0~255,
16~235
EDID Version Extended Display Identification Data. This is the protocol that allows the PC or Mac know what
driver or device is attached as an extended monitor. The version of EDID is provided by the PC or Set
Top Box.
Default (2.0),
EDID1.4,
EDID2.0
HDMI-CEC Consumer Electronics Control Off/On
79 ActivPanel System Install and User Guide
