Pronomic TL 200 - Page 18

Power amplifier TL series
16 Pronomic TL Serie / ArtNr.: 00063864/00021732/00021733/00021734 2022-11-21
PARALLEL (MONO) –MODE
Do not use the "PARALLEL (MONO)" setting when feeding the
separate signals from another power amplifier.
1. Check if the power amplifier is switched off.
2. Set the MODE SELECTOR (16, on the back of the unit) to the "PARALLEL"
position.
3. Connect the input / output lines properly as shown in the illustration above.
