05. Footwell assembly & use
① Separate the footwell padding from the footwell board.
② Pull on straps and remove from the base.
③ Pulling on the straps will unclip the footwell board from the bottom.
④ Insert and lower the separated floor board down to the bottom.
⑤ Lower the footwell board to the bottom and make sure that the waterproof fabric is facing up.
9
Accembly
5
①
① ② ③
④ ⑤
footwell side view
⑥
Warning! Please do not allow your child to jump on the footwell. It may cause damage or injury.
Top side of
footwell padding
To Next Page
