FUNCTIONS -ARRAY SPEAKER
DSP SETTINGS
1. SERIES OUT
Adjust this switch to determine whether the signal is provided from one speaker to the next in either series
or parallel.
2. INPUT
Provides input to the speaker from the subwoofer or another satellite via ¼” TS Jack.
3. PARALLEL OUT
Provides output for a parallel connection via ¼” TS Jack.
4. SERIES OUT
Provides output for a serial connection via ¼” TS Jack.
PR-204V
1
2
3
4
STANDARD
A clear and accurate sound. The low and high roll-offs, combined with a slight mid cut give clarity making
this setting ideal for theatrical or speech orientated events.
Examples
• Theatrical productions
• Awards and dinner events
STANDARD
DJ 1
DJ 2
LIVE
12
