15. USB Port
16. SD/MMC Slot
17. (Phones) Jack
18. AV OUT Jack
19. AV IN Jack
20. POWER ON/OFF Switch: Slide to ON
position to power on. Slide to OFF position to
shut off.
21. DC IN Jack:
)
15 16 18 19 20 21
LOCATION OF CONTROLS
ON
OFF
DC IN
AV-IN
AV-OUT
SD/MMC
USB
22
23
22. Indicator
23. Remote Sensor
Right Side View:
Front Side View:
17
DC input jack (DC 9-12V, 1A
