CONTROL REFERENCE GUIDE
FRONT VIEW
1.Color Screen
2.Remote Sensor
Do not block this sensor or the
remote control will not work.
3.Standby Indicator
Indicates whether the unit is ON
or in STANDBY (OFF) mode.
Light in red: The unit is in STANDBY.
Light in blue:The unit is turned ON.
4.Speakers
BACK VIEW
1.Power Cord
2.PC ADUIO IN Jack
3.VGA IN Jack
4.TV ANTENNA Terminal
5.HDMI IN Jacks
6.COMPONENT IN Jack
7.AV IN Jack
8.Coax OUT Jack
9.Service Port
10.Headphone Jack
