1. FEATURES
Easy and correct readout.
High measuring accuracy.
Measurements are possible even under a strong magnetic field.
LSI-circuit provides high reliability and durability.
Input overload protection is provided.
LCD display for low power consumption and clear readout even in bright
ambient light conditions.
Light-weight and compact construction for easy operation.
Low battery condition is indicated on the LCD display.
2. SPECIFICATIONS
2-1.GENERAL SPECIFICATIONS
Display: LCD (Liquid Crystal Display) Max . Indication 1999.
Measurement: C (Capacitance)
Range: single 9 position, whole range value (from 0.1pF to 20000uF)
Zero Adjustment :Manual (range: 20pF)
Calibrate Adjustment: Have two internal adjustments. One is panel Zero
adjustment.
Over-input :Display shows 1 .
Backlight Function: it went out by itself within 8 seconds.
Sampling Time: 0~5second
Operating Temp :0 to 40
Operating Humidity: 80% MAX.R.H.
Power Supply : Single, standard 9 volt battery. NEDA 1604IEC6F22
Typical consumption current: 3~4mA (RANGE: 200pF-200uF)
Standard Accessories: Test alligator clips (red & black) …1 pair.
Instruction manual………… ……..1 pc.
