ProStar PS-15 - Wiring

Installation
ProStar Operator’s Manual
21
20
3.0
Figure 3-2. Proper Clearances for Passive Cooling
3.4 Wiring
To battery (+) and
(-) terminals for
Not used in this illustration
voltage sensing
To battery for
temperature
sensing
To battery (+)
and (-)
terminals
To load (+)
and (-)
terminals
To properly
sized array
1
4
6
7
2
3
5
REFER TO FIGURE 3.3 WHEN USING THE FOLLOWING
WIRING INSTRUCTIONS
Figure 3-3. Wiring the ProStar
