Operation
ProStar Operator’s Manual
47
46
4.0
Color Indication Operating State
None Off (with heartbeat¹) Night
Green
On Solid
( with heartbeat² )
Charging
Red Flashing Error
Red
On Solid
( with heartbeat
2
)
Critical Error
¹ heartbeat indication flickers the Status LED on briefly
every 5 seconds
² heartbeat indication flickers the Status LED off briefly
every 5 seconds
Table 4.4. Status LED Definitions
NOTES:
1) R flashing is generally a user addressable fault /
error
2) R charging status LED ON with heartbeat blink OFF
every 5 secs is a critical fault that generally requires
service. See, “Solid Charging Status LED with Self-
test (R-Y-G) SOC Faults”, in Section 5.2.
4.3.3 State-of-Charge LEDs
Battery SOC LED Indications are shown in Table 4-3
below:
Condition Indication
Absorption G flash - every sec
Float
G flash - every 2 secs
Equalize
G flash - 2 / sec
SOC > 13.5V
G solid
13.5V > SOC > 13.0V
G / Y solid
13.0V > SOC > 12.5V
Y solid
SOC < 12.5V
Y / R solid
Low voltage disconnect warning
R flash - every sec
Low voltage disconnect
R solid
Table 4.5. Battery SOC LED Indications
4.4 Push-Button Use in Non-Metered Versions
The non-metered version of the ProStar features a
push-button that operates as follows depending on
the DIP Switch 1 setting:
Normal Mode (DIP 1 OFF)
• One quick press and release will clear any faults or
reminders that are present
• If unit is set to manual EQ, press and hold the push-
button for 5 seconds to initiate an Equalization (EQ).
