Installer Guide
1
Select Cool or Heat with the Mode Switch.
2
Normally leave the fan s
witched to
Auto.
In Fan
Auto, the fan will turn on only with a heat or cool demand.
When Fan On is selected,
the fan will run continuously
.
3
Adjust the desired set temperature with the
COOLER and
W
ARMER buttons.
Operation
2
Normal Operation
COOLER &
WA
RMER
BUT
TO
NS
HE
AT
BATTERIES
COOL
OFF
FA
N
HE
AT
AU
TO
ON
On or
Auto
FA
N SWITCH
MODE SWITCH
Cool, Of
f,
or Heat
AUX HE
AT
NORM
EMRGC’Y LOCKOUT
6
8
