ProSystems SIZE 1.0 - Page 16

16
Item Quantity Aquion Part # Description
1 1 70793 3/4” NPTF TO 1/2” I.D. HOSE MALE DRAIN ELBOW
2 1
75053
72175
BACKWASH FLOW CONTROL 2.5 GPM (UNIT SIZE 1.0 & 1.5)
BACKWASH FLOW CONTROL 3.5 GPM (UNIT SIZE 2.0)
3 6 72678 SCREW 1/4-20 X 1-1/4 LG HEX WASHER HD
4 1 71083 VALVE BODY COVER
5 1 70658 VALVE COVER O-RING
6 1 72327 WASHER
7 1 70665 TEFLON O-RING
8 1 71089 WORM GEAR
9 1 71087 CAM SHAFT
10 1 70656 ROTOR O-RING
11 1 71132 ROTOR PLATE
12 1 71084 SEAL DISK
13 1 71182 INSERT PLATE
14 1 71183 GASKET
15 1 71006 FLOAT VALVE SPRING
16 1 71127 FLOAT VALVE
17 1 70660 FLOAT VALVE O-RING
18 1 72679 VALVE BODY
19 1
71063
71064
INJECTOR #1 (UNIT SIZE 1.0 & 1.5) RED
INJECTOR #2 (UNIT SIZE 2.0) YELLOW
20 1 70655 INJECTOR O-RING LOWER
21 1 70664 INJECTOR O-RING UPPER
23 1 71947 SPRING CLIP
24 1 71344 RISER INSERT GASKET
25 1 71118 RISER INSERT
26 1 70662 RISER TUBE O-RING
27 1 70663 TANK O-RING
28 1 71010 ADAPTER RING
29 2 71512 SCREW 6-20 X 21/32 LG SS
30 1 71060 WORM DRIVE SHAFT
31 1 70616 WORM DRIVE SHAFT WASHER
32 2 70666 WORM DRIVE SHAFT O-RING
33 1 70661 PACKING GLAND O-RING
34 1 71069 PACKING GLAND NUT
35 1 70667 O-RING
36 1 70659 O-RING
37* 1 70932 UMBRELLA CHECK VALVE(*OPTIONAL FOR OVERHEAD DRAINS)
38 1 71124 BRINE REFILL ELBOW
39 1 71961 REFILL ELBOW CHECK BALL 1/4” DIA
40 1 70984 REFILL ELBOW SPRING
41 2 70797 COMPRESSION NUT FOR 3/8” TUBE JACO
42 1 71184 BRINE REFILL FLOW CONTROL
43 1
70994
70995
FLOW CONTROL WASHER 0.5 GPM (UNIT SIZE 1.0 & 1.5)
FLOW CONTROL WASHER 1.0GPM (UNIT SIZE 2.0)
44 1 71129 BRINE TEE
45 1 70871 BRINE TEE CHECK BALL 3/8” DIA
46 2 12625 3/8” TUBE SUPPORT
47 1 13604 BRINE REFILL TUBE 3/8” O.D.X. 250” I.D. X 12” L
48 1 70797 COMPRESSION NUT FOR 3/8” TUBE JACO PG-6
49 1 72458 FLOW DIFFUSER
50 1 72544 IMPELLER ASSEMBLY WITH BUSHING
51 1 72545 HUB FLOW METER ASSEMBLY
52 1 72519 FLOW METER SENSOR CABLE 20”
VALVE PARTS LIST
