ProTeam ProGen 1073300 - ATTENTION Clutch, LED Front Light, Belts, and Control Boards

Clutch, LED Front Light, Belts, and Control Boards
2 www.pro-team.com 866.888.2168
Lift straight up on sensor control board, do not
lift by wires
4.
Remove rubber bumper - Pull straight up
1.
Remove lens - Lift up on corner
2.
Remove LED light - Lift straight up on sensor
control board, do not lift by wires
5.
Remove RPM sensor - Remove screw
(M4 x 16mm length)
3.
6.
Remove printed circuit board - Remove two (2)
screws (M4 x 16mm length)
