protech Enigma XTR Scale 1/8 4WD User Manual

9
Assembly of the front suspension / Montage van de voorste ophanging /
Montage de la suspension avant / Montierung von die vordere Querlenker oben
4mm x 10mm (x2)
MA2054
6mm x 60mm
(x2)
Approx. 7mm
Approx. 7mm
Approx. 15mm
Front upper suspension arm
Bras supérieur de suspension avant
Voorste bovenste ophangingsarm
Vorderer Querlenker oben
T56.028
Turnbuckle
Barre de réglage
Stang
Gestange
T56.031
8mm x 35mm
Ball end + ball
Chape
Kogelgewricht
Kugelgelenkträger
T56.030
Front lower suspension arm
Bras inférieur de suspension avant
Voorste onderste ophangingsarm
Vorderer Querlenker unten
T56.026
6mm x 30mm
T56.089
x2
x2
4mm x 10mm
Ball end + ball
Chape
Kogelgewricht
Kugelgelenkträger
T56.030
L R
