RANGE RESOLUTION ACCURACY
200mV 100µV ±(0.5% reading + 2 digits)
2V 1mV ±(0.5% reading + 3 digits)
20V 10mV
±(0.8% reading + 3 digits)
200V 100mV
500V 1V ±(0.8% reading + 5 digits)
RANGE RESOLUTION ACCURACY
200V 0.1V
±(1.8% reading + 10 digits)
500V 1V
MEASUREMENT SPECIFICATIONS
The following guide is based on an environmental temperature of
18-28°C and humidity <80%.
DC VOLTAGE
Overload Protection: 200mV range at 250VDC or 250VAC RMS
Other ranges at 600VDC or 600VAC RMS
AC VOLTAGE
Overload Protection: 500VDC or 500VAC RMS
Frequency Range: 40~400Hz
10
