protech QM1527 - Current, Resistance, and Output Specifications; DC Current Specifications and Accuracy; Square Wave Output Specifications; Resistance Specifications and Accuracy

RANGE RESOLUTION ACCURACY
200µA 0.1µA
±(1.0% reading + 5 digits)2mA 1µA
20mA 10µA
200mA 100µA ±(2.0% reading + 5 digits)
10A 10mA ±(3.0% reading + 5 digits)
DC CURRENT
Overload Protection: Fuse F200mA/250V
No fuse for 10A range
SQUARE WAVE OUTPUT
OUTPUT
FREQUENCY
VP-P IMPEDENCE
50Hz ±10Hz 5V±2V 560kΩ
RESISTANCE
Overload Protection: 250VDC or 250VAC RMS
Maximum Open Circuit Voltage: <3.2V
RANGE RESOLUTION ACCURACY
200Ω 0.1Ω
±(1.0% reading + 2 digits)
2kΩ 0.001kΩ
20kΩ 0.01kΩ
200kΩ 0.1kΩ
2MΩ 0.001MΩ
11
