protech QM1549 User Manual

RANGE RESOLUTION ACCURACY
400µA 0.1µA ±(1.5% reading + 5 digits)
4000µA 1µA
±(1.8% reading + 5 digits)40mA 10µA
400mA 100µA
10A 10mA ±(3.0% reading + 5 digits)
AC CURRENT
DC CURRENT
RANGE RESOLUTION ACCURACY
400µA 0.1µA ±(1.0% reading + 3 digits)
4000µA 1µA
(1.5% reading + 3 digits)40mA 10µA
400mA 100µA
10A 10mA ±(2.5% reading + 5 digits)
Overload Protection: 0.5A/1000V and 10A/1000V fuse
Maximum Inputs: 400mA DC RMS on µA/mA ranges, 10A DC RMS on 10A
range. All µA and mA DC currents are autoranging.
Overload Protection: 0.5A/1000V and 10A/1000V fuse
Frequency Range: 50~400Hz
Maximum Inputs: 400mA AC RMS on µA/mA ranges, 10A AC RMS on 10A
range. All µA and mA AC currents are autoranging.
11

protech QM1549 Specifications

General

Brand	protech
Model	QM1549
Category	Multimeter
Language	English
