protech QM1549 User Manual

RANGE RESOLUTION ACCURACY
4nF 1pF ±(5.0% reading + 0.1nF)
40nF 10pF ±(5.0% reading + 7 digits)
400nF 0.1nF
±(3.0% reading + 5 digits)4µF 1nF
40µF 10nF
100µF 0.1µF ±(5.0% reading + 5 digits)
CAPACITANCE
Overload Protection: 600VDC or 600VAC RMS
DUTY CYCLE
RANGE RESOLUTION ACCURACY
0.1~99.9% 0.1% ±(1.2% reading + 2 digits)
12
Pulse Width: >100µs, <100ms
Frequency Width: 5Hz-150kHz
Sensitivity: >0.8V RMS
Overload Protection: 600VDC or 600VAC RMS
RESISTANCE
Input Protection: 600VDC or 600VAC RMS
RANGE RESOLUTION ACCURACY
400Ω 0.1Ω ±(1.2% reading + 4 digits)
4kΩ 1Ω ±(1.0% reading + 2 digits)
40kΩ 10Ω
± (1.2% reading + 2 digits)400kΩ 100Ω
4MΩ 1kΩ
40MΩ 10kΩ ± (2.0% reading + 3 digits)

protech QM1549 Specifications

General

Brand	protech
Model	QM1549
Category	Multimeter
Language	English
