FUNCTIONS
Max. Display 4000 Count
Basic Accuracy 0.5%
DC Voltage Range 400mV - 1000V
AC Voltage Range 400mV - 1000V
DC Current Range 4mA -10A
AC Current Range 4mA - 10A
Resistance 400Ω - 40MΩ
Capacitance (CAP) 4nF - 100µF
Frequency (Hz) Up to 10MHz
FUNCTIONS
Continuity Yes
Data Hold Yes
Relative
Measurement
Yes
Diode Test Yes
Duty Cycle Yes
Autoranging Yes
LCD Backlight Yes
Auto Power Off Yes
The fuse & battery compartment are at the rear of the multimeter.
LCD Screen
Hz% Button
Range Button
Mode Button
Relative Button
Function
Switch
COM Input Jack
Hold Button
Backlight Button
Positive VΩCAP
Input Jack
Positive mA, μA
Input Jack
10A Input Jack
3
